We're professional 2 ton pallet stacker manufacturers and suppliers in China, to buy or wholesale ride on pallet stacker from our factory. For quotation or if you have any questions, contact us now for customized stand on pallet stacker and price.
2 ton pallet stacker is a flagship stand-on electric pallet stacker, with a large load capacity and high lifting height. It is equipped with a foldable stand-on pedal, providing smooth operation and an excellent driving experience. It is highly efficient and suitable for warehouse and workshop operations.
Technical parameter of 2 ton pallet stacker
![]()
| Characteristics |
| Model |
| CDD-DS |
| Driving type |
| Stand-on |
| Rated loading capacity | Q(kg) | 2000 |
| Mast type |
| Triplex Mast |
| Lifting height | h3(mm) | 4000/4500/5000/5500 |
| Service weight with battery | kg | 1130/1160/1190/1230 |
| Load center | c(mm) | 500 |
| Axle center to fork | x(mm) | 764 |
| Wheel base | y(mm) | 1457.5 |
| Controller |
| LVM24S20 |
| Wheels |
| Wheels type |
| PU |
| Driven wheel | ∅×w (mm) | φ250×80 |
| Load wheel | ∅×w (mm) | φ80×60 |
| Stabilizing wheel | ∅×w(mm) | φ115×55 |
| Wheels, number front/ rear(x= driven) |
| 1x, 2/4 |
| Dimensions |
| Mast closed height | h1(mm) | 1900/2070/2240/2410 |
| Mast extended height with load-backrest | h4 (mm) | 4506/5010/5514/6016 |
| Minimum height of fork surface | h1 3 (mm) | 88 |
| Overall length | L1 (mm) | 2125 |
| Length without fork | L2 (mm) | 965 |
| Overall width | b1/b2 (mm) | 1150 |
| Fork dimensions | s/e/L (mm) | 55/165/1150 |
| Fork outside width | b5(mm) | 550/685 |
| Min. Ground clearance | m2 (mm) | 30 |
| Ais le width (pallet 1000x1200) Load center C500mm | Ast (mm) | 2608 |
| Ais le width (pallet 800x1200) Load center C500mm | Ast (mm) | 2536 |
| Min. Turning radius | Wa(mm) | 1744 |
| Performance |
| Travel speed, with/ without load | km/h | 5.5/5.8 |
| Lifting speed, with/ without load | mm/s | 75/125 |
| Descending speed, with/ without load | mm/s | 95/100 |
| Max. gradeability load/ unload | % | 5/8 |
| Brake |
| Electromagnetic |
| Drive and Battery |
|
|
| Drive motor power S2 60 min. | kW | 1.6 |
| Lift motor power at S3 15% | kW | 2.2 |
| Battery voltage/ rated capacity | V/ Ah | 24/210 |
| Battery weight(±5%) | kg | 180 |
| Others |
| Noise level | dB (A) | <70 |
| Steering type |
| Mechanical Steering |
2 ton pallet stacker manufacturer
Diding Lift focuses on providing high-quality 2 ton pallet stacker and excellent service since 2015. We are a professional 2 ton pallet stacker manufacturer and factory of 65,000 M2 which mainly produce Electric Pallet Truck, Electric Stacker, Reach Truck products for around 12 years’ experience. Diding provides you with rideable electric pallet jack wholesale, customization, design, packaging, industry solutions and OEM & ODM service.
![exhibition site]( "exhibition site")
![exhibition site]( "exhibition site")
![exhibition site]( "exhibition site")
![delivery site]( "delivery site")
![delivery site]( "delivery site")
![delivery site]( "delivery site")
Where to buy 2 ton pallet stacker?
If you have any questions about 2 ton pallet stacker, ride on pallet stacker, stand on pallet stacker,electric stacker 2 ton, please don't hesitate to send email to sales@didinglift.com at any time. We will provide detailed information and technical support about the features, specifications, solutions and customization options of Electric Pallet Truck, Electric Stacker, Reach Truck... Welcome you to visit our factory!
